Model No.
|
CyberBox 3000
|
Battery Specification
|
Battery Type
|
LiFePO4(Lithium iron phosphate)
|
Battery Voltage
|
12.8V
|
Capacity
|
200Ah
|
|
Battery Lifespan
|
2000+ Life cycles
|
BMS Capability
|
250A
|
Output Specification
|
AC Rate Power / Surge Power(max)
|
3000W / 6000W
|
AC Continuous Output Voltage
|
100-120V / 220-240V
|
AC Rated Frequency
|
50Hz / 60Hz
|
AC Outlet
|
3 x AC Outlet (max 3000W)
|
DC Outlet
|
2 x 12V 10A socket
|
2 x USB3.0 + PD
|
1 x Merit socket
|
1 x Engal socket
|
2 x 12V 50A input/output
|
1 x 12V 175A outlet
|
Input Specification
|
AC Charger
|
Input: 100-120V / 220-240V AC, 50/60Hz, 10A
|
Output: 14.6V 40A
|
DC-DC MPPT solar charger
|
ALT input: 12-16VDC
|
Solar input: 12-25VDC
|
LVD: 11.6V / 12.8V
|
Output: 14.6V 30A / 40A
|
EN60335, EN60335, EN55014, EN61000
|
Operating Environment
|
Relative Humidity: 10%-90%
|
Operating Temperature: -10℃ to 50℃
|
Dimension
|
L420*265*345mm
|
|
Net Weight
|
29.00KG
|
|
