Specifications
| Model No. | DC Battery Box |
| Applicable Battery Specification | |
| Battery Type | LiFePO4/Lead acid/AGM/Gel |
| Battery Voltage | 12V |
| Capacity | 70Ah to 230 |
| Battery Size | L330*W175*H220mm |
| Battery Weight | Max 35.00Kg |
| Output Specification | |
| DC Outlet | 1 x 12V 10A socket |
| 2 x USB3.0 + PD | |
| 1 x 10A solar input(max 45V) | |
| 3 x 12V 50A input/output | |
| 1 x 12V 175A outlet | |
| Input Specification | |
| AC Charger | Input: 100-120V / 220-240V AC, 50/60Hz, 10A |
| Output: 14.6V 40A | |
| Solar MPPT charge | Max charging current: 10A |
| System volt: 12V | |
| Max input power: 130W | |
| Max volt on battery terminal: 25V | |
| Operating Environment | Relative Humidity: 10%-90% |
| Operating Temperature: -10℃ to 50℃ | |
| Dimension | L455*W240*330mm |
| Weight | 11KG |
